A port injector flow test is a diagnostic procedure used to measure how much fuel each fuel injector delivers through the intake ports of an internal combustion engine over a specific period. It's commonly used in automotive maintenance and performance tuning to check for:

• Clogged or dirty injectors

• Uneven fuel delivery between cylinders

• Leaking injectors

• Malfunctioning injector solenoids or electronics


To ensure consistent and correct fuel flow from each injector, which is critical for engine performance, efficiency, and emissions control.

1. Test Equipment Setup:

   • The injectors are either tested on the vehicle (in-situ) using specialized equipment or removed and tested on a flow bench.

   • In either case, a measured amount of test fluid or fuel is passed through each injector while it is pulsed open using a controller.


1. Flow Measurement:

   • The fuel or fluid that comes out of each injector is collected in graduated cylinders or containers.

   • The amount of fluid is compared across all injectors to ensure they are delivering evenly and to spec.


1. Leak & Spray Pattern Test (optional):

   • The injectors may also be checked for leaks when closed.

   • The spray pattern is observed to ensure proper atomization.


• Good injectors should all deliver similar volumes and have uniform spray patterns.

• Bad injectors may show:

  • Low flow (clogged or dirty)

  • High flow (leaking or stuck open)

  • Irregular spray patterns


• Diagnosing misfires or rough idle

• Engine tuning or modifications

• Pre- or post-cleaning injector verification

• Preventive maintenance for high-performance engines


If you're doing this for a specific engine or vehicle—some setups have unique testing requirements.
